Technical Specifications
Performance


Input Power: 6000 Watts

Propulsive Power: 3504 Watts

Comparable Petrol Outboards (Propulsive Power): 9.9 HP

Comparable Petrol Outboards (Thrust): 15 HP

Maximum Overall Efficiency: 58%

Static Thrust: 230 lbs

Electrical System


Nominal Voltage: 48V

TorqLink Compatible: Yes

Integrated On-Board Computer: Yes

Dimensions & Weight


Total Weight: 20.6 kg (S) / 21.0 kg (L)

Shaft Length: 62.5 cm (S) / 75.5 cm (L)

Propeller Details


Standard Propeller: Propeller B 12.5 x 17 HSP

Alternative Propeller Option: Propeller B 12 x 13 THR

Maximum Propeller Speed: 1130 RPM

Control & Steering


Control Type: Remote Throttle

Steering: Compatible with standard remote steering system; lockable

Stepless Forward & Reverse Drive: Yes

Tilt & Trim Features


Tilting Device: Manual with grounding protection

Tilt Angle: 360° lockable

Trim Device: Manual, 4-step
