EKKO EK50LP LPG Forklift – 10,000 lbs Capacity | 185″ Lift Height

The EKKO EK50LP Liquid Propane 4-Wheel Forklift is built for demanding material handling, warehousing, and distribution applications. Designed with durable construction, Tier 4 EPA compliance, and powered by a Kubota engine, this forklift delivers reliable performance and efficient operation in industrial environments.

The forklift features a multifunction instrument panel for monitoring safe and efficient operation, along with an operator-focused compartment designed for comfort and visibility. A non-slip entrance step, wider access area, additional leg room, and adjustable steering column help reduce operator fatigue during extended use.

Its integral heavy-duty chassis enhances driver protection, while the steer axle pivots up to 80 degrees for a tighter turning radius and improved maneuverability. Hydraulic controls provide smooth handling and lifting performance.
Features


10,000 lbs load capacity

185″ lift height

LPG (Liquid Propane) powered

Tier 4 EPA compliant Kubota engine

Multifunction instrument panel

Adjustable steering column

Non-slip entrance step

Wider operator access and leg room

Excellent operator visibility

Heavy-duty chassis for driver protection

Hydraulic controls

Steer axle pivots to 80 degrees for tighter turning radius

Specifications


Model: EK50LP

Drive Type: LPG

Operation Type: Propane

Load Capacity: 10,000 lbs

Load Center: 24 in.

Lift Height: 185 in.

Wheelbase: 61.8 in.

Service Weight: 16,250 lbs

Tire Type: Cushion Tires

Traction Pin Height: 11.2 in.

Service Brake: Hydraulic Foot Pedal

Parking Brake: Mechanical Hand Lever

Overall Width: 55.9 in.

Overall Length with Forks: 157 in.

Overall Length without Forks: 109 in.

Minimum Ground Clearance at Mast: 4.3 in.

Maximum Travel Speed (Loaded/Unloaded): 10.5 / 11.2 MPH

Mast Overall Height: 91.9 in.

Free Lifting Height: 44.3 in.

Backrest Height from Fork Surface: 47.6 in.

Fork Size: 48 × 5.9 × 1.97 in.

Engine Model: Kubota WG3800

Engine Power: 63.2 HP

Available now at stoolby.com.
