16TL Super Duty Tilt Bed Equipment Trailer
Upgrade your productivity and versatility with the 16TL Super Duty Tilt Bed Equipment Trailer from stoolby.com. Available in multiple models from 20 ft. to 22 ft., this trailer features a stationary front deck and a rear tilt deck, providing flexible loading options for low-profile equipment. With a 14° tilt deck angle and a 1/4 in. diamond plate knife edge, loading and unloading equipment is quick and efficient. Built with heavy-duty construction and multiple cargo securement points, this trailer is designed for long-term durability and dependable performance.
Standard Features


2 – 8,000 lb premium axles with oil bath and Valcrum caps

Forward self-adjusting electric brakes on both axles

Torsion axle suspension

Adjustable 2-5/16 in. Demco EZ Latch coupler

3/8 in. Grade 70 safety chains with safety latch hooks

12,000 lb drop-leg jack (side wind)

8 in. channel frame construction

3 in. channel cross-members on 16 in. centers

3/16 in. fabricated front stop rail

APEX fortified lumber floor

9 in. x 72 in. 14-gauge diamond plate removable fenders

Stake pockets along both sides

7-way RV trailer plug

Recessed grommet-mounted LED lighting

Sealed modular cold-weather wiring harness

ST215/75 R-17.5 Load Range E radial tires

8-bolt wheel pattern

Hydraulic dampening tilt deck with valve control

EZ pedal locking mechanism

Rub rail along both sides

(6) 5/8 in. D-rings for cargo securement

Complete breakaway system with Zip™ breakaway cable and charger

Professional primer finish with standard black paint

Available Options


Adjustable pintle in channel in place of coupler

Blackwood Pro rubber infused lumber floor

1/8 in. diamond plate steel floor

Front spare tire mount

Spare tire upgrade (ST235/80 R-16 LR-G)

Additional 5/8 in. D-rings

Recessed floor D-rings (steel floor only)

Multiple paint color options including red, grey, white, desert tan, jet blue, slime green, implement green, equipment orange, and medium yellow

Tilt Deck Dimensions


75 in. wide tilt deck

83 in. between fenders

1/4 in. diamond plate knife edge

Model Specifications



Model
16TL-20
16TL-22
16TL-20GN
16TL-22GN




Pull Type
Bumperpull
Bumperpull
Bumperpull
Bumperpull


GVWR
17,500 lbs
17,500 lbs
17,500 lbs
17,500 lbs


GAWR (Each Axle)
7,000 lbs
7,000 lbs
7,000 lbs
7,000 lbs


Empty Weight
4,080 lbs
4,140 lbs
4,880 lbs
4,940 lbs


Cargo Capacity
13,420 lbs
13,360 lbs
12,620 lbs
12,560 lbs


Bed Length
20 ft.
22 ft.
20 ft.
22 ft.


Bed Width
83 in.
83 in.
83 in.
83 in.


Tongue Length
47 in.
47 in.
47 in.
47 in.
