30SV Single Axle Vanguard Trailer
When it’s time to work, it’s time for the 30SV Single Axle Vanguard Trailer. Built strong to haul landscaping equipment and tools from job to job, the 30SV is designed for dependable performance and hassle-free transport. Featuring a durable pipe-top rail and higher side panels, this trailer helps protect cargo while keeping equipment secure during travel. Optional rear ramp gate upgrades allow for easy loading of golf carts, ATVs, side-by-sides, lawn equipment, and more.
Key Features


3,500 lb Premium Cambered Axle with quick-lubricating hubs

Multi-Leaf Slipper Spring Suspension for smooth towing

Demco EZ Latch 2″ Forged Coupler for secure connection

Heavy-Duty Steel Frame Construction with 3″ x 2″ x 3/16″ angle frame and cross-members

28-1/2″ Tall Sides with 24″ V-crimped steel panels for added cargo protection

Treated Pine or Douglas Fir Floor for durability and long service life

LED D.O.T. Stop, Tail, Turn & Clearance Lights

Lifetime Grommet-Mounted LED Wiring System

Tie-Down Loops Inside Bed for cargo security

Professional Finish with Primer available in multiple color options

Optional Rear Ramp Gate for loading ATVs, golf carts, lawn equipment, and side-by-sides

Available Options


Electric Brakes with Complete Break-Away Kit

4 ft or 5 ft Rear Ramp Gate with Coil Spring Assist

Additional Stake Pockets & Tie Loops

Fold-Up Jack Upgrade

Blackwood Pro Rubber Infused Lumber Floor

Spare Tire & Side Spare Tire Mount

Bolt-On Landscape Storage Box




Model Specifications
30SV-08


Pull Type: Bumperpull

GVWR: 2,995 lbs

GAWR (Each Axle): 3,500 lbs

Empty Weight: 870 lbs

Cargo Capacity: 2,125 lbs

Bed Length: 10 ft

Bed Width: 60 in.

Tongue Length: 36-1/8 in.




30SV-10


Pull Type: Bumperpull

GVWR: 2,995 lbs

GAWR (Each Axle): 3,500 lbs

Empty Weight: 970 lbs

Cargo Capacity: 2,025 lbs

Bed Length: 12 ft

Bed Width: 60 in.

Tongue Length: 36-1/8 in.




30SV-12


Pull Type: Bumperpull

GVWR: 2,995 lbs

GAWR (Each Axle): 3,500 lbs

Empty Weight: 1,070 lbs

Cargo Capacity: 1,925 lbs

Bed Length: 14 ft

Bed Width: 60 in.

Tongue Length: 36-1/8 in.
