70ST Single Axle Tilt Trailer
Overview
The 70ST Single Axle Tilt Trailer is a compact and budget-friendly equipment trailer designed for hauling smaller vehicles, light-duty equipment, ATVs, and compact machinery. With its hydraulic tilt deck system, durable steel construction, and low loading angle, it offers fast and easy loading without the need for ramps.



Key Features


Hydraulic dampening tilt deck system

7,000 lb single drop axle

12° tilt angle for easier loading

5" channel steel frame

Rub rail along both sides

LED recessed trailer lighting

Quick-lubricating hubs

Diamond plate knife edge for smooth loading

Adjustable forged coupler

8,000 lb drop-leg jack




Construction & Design
Frame


Heavy-duty 5" channel frame

3" channel cross-members on 16" centers

Tilt Deck


Hydraulic dampening system with deck lock

Low-angle loading design

Tilt deck dimensions:


81" wide

1/4" diamond plate knife edge



Flooring


Standard APEX fortified lumber floor

Optional:


Blackwood Pro rubber-infused lumber

Diamond plate steel floor






Axles & Suspension
Axle


1 x 7,000 lb drop axle

Quick-lube hubs

Suspension


Multi-leaf slipper spring with equalizer

Tires


ST235/80 R-16 Load Range E radial tires

Optional LR-G tire upgrade




Lighting & Wiring


Recessed LED lighting

Sealed cold-weather wiring harness

7-way RV trailer plug




Safety Features


Forward self-adjusting electric brakes

Complete breakaway system with charger

Grade 70 safety chains

Adjustable forged coupler

Front stop rail




Available Models
70ST-13


Bed Length: 13 ft

Bed Width: 83 in.

Empty Weight: 2,110 lbs

Cargo Capacity: 4,890 lbs

GVWR: 7,000 lbs

70ST-16


Bed Length: 16 ft

Bed Width: 83 in.

Empty Weight: 2,310 lbs

Cargo Capacity: 4,690 lbs

GVWR: 7,000 lbs




Standard Equipment


Adjustable forged coupler

8,000 lb drop-leg jack

Stake pockets along both sides

Rub rail

4 heavy-duty D-rings

Removable diamond plate fenders

LED DOT lighting

Hydraulic tilt system




Optional Upgrades


2-5/16" adjustable coupler

Spare tire & wheel

LR-G tire upgrade

Extra D-rings

Steel flooring

Blackwood Pro flooring




Best Uses


ATVs and UTVs

Compact tractors

Small skid steers

Lawn equipment

Golf carts

Light-duty machinery hauling




Why Choose the 70ST Tilt Trailer?
The 70ST Single Axle Tilt Trailer is ideal for users wanting:


Easy loading without ramps

Reliable light-duty hauling

Lower loading angles

Durable construction

Budget-friendly performance

Its tilt deck system and compact design make it an excellent choice for transporting smaller equipment efficiently and safely.
