14TL Heavy Duty Tilt Bed Equipment Trailer
Designed for maximum productivity and smooth equipment loading, the 14TL Heavy Duty Tilt Bed Equipment Trailer combines rugged construction with a highly functional tilt deck system. Featuring both a stationary front deck and a hydraulic rear tilt deck, this trailer is built to handle demanding equipment hauling tasks with efficiency and control.

Whether you're transporting skid steers, tractors, small excavators, or other heavy equipment, the 14TL delivers dependable performance with premium-grade components and smart loading features.
Key Features


14,000 lb GVWR

Up to 10,540 lb cargo capacity

Hydraulic dampening tilt deck system

Stationary front deck + rear tilt deck

12° tilt angle for easier loading

6-inch channel frame construction

4-inch drop axles

1/4-inch diamond plate knife edge

Rub rail and stake pockets for cargo securement

LED recessed lighting

Heavy-duty adjustable coupler system

Available in bumper pull and gooseneck models

Efficient Tilt Deck Design
The rear tilt deck uses a hydraulic dampening system with valve control for smoother loading and unloading operations. The EZ pedal locking mechanism provides convenient deck operation while maintaining safety and stability during use.

The integrated diamond plate knife edge and low loading angle help make equipment loading safer and easier.
Heavy-Duty Construction
Built with a rugged 6-inch channel frame and reinforced cross-members, the 14TL is engineered for long-term durability in demanding work environments.

Additional heavy-duty components include:


Premium 7,000 lb drop axles

Multi-leaf slipper spring suspension

Adjustable coupler system

Removable diamond plate fenders

Fabricated front stop rail

Versatile Cargo Handling
The trailer includes multiple cargo securement features such as:


Stake pockets along both sides

Rub rails

Six 5/8-inch D-rings

Optional recessed D-rings

Adjustable pintle hitch option

These features help safely secure heavy equipment and oversized loads.
Smooth Towing & Reliable Performance
Equipped with:


Forward self-adjusting electric brakes

ST235/80 R-16 radial tires

Sealed modular cold-weather wiring harness

LED lighting system

The 14TL delivers reliable towing performance and dependable braking under heavy loads.
Available Models
The 14TL is available in multiple lengths and configurations, including bumper pull and gooseneck setups for different hauling needs.
Model Specifications



Specification
14TL-22
14TL-20GN
14TL-20
14TL-22GN




Pull Type
Bumperpull
Gooseneck
Bumperpull
Gooseneck


GVWR
14,000 lbs
14,000 lbs
14,000 lbs
14,000 lbs


Empty Weight
3,660 lbs
3,460 lbs
3,460 lbs
3,660 lbs


Cargo Capacity
10,340 lbs
10,540 lbs
10,540 lbs
10,340 lbs


Bed Length
22 ft
20 ft
20 ft
22 ft


Bed Width
83 in
83 in
83 in
83 in


Tilt Deck Width
75 in
75 in
75 in
75 in


Tongue Length
48-1/2 in
48-1/2 in
48-1/2 in
48-1/2 in



Ideal For


Equipment transport

Construction contractors

Landscaping professionals

Tractor hauling

Skid steer transport

Farm and ranch applications

The 14TL Heavy Duty Tilt Bed Equipment Trailer combines strength, smooth loading capability, and professional-grade hauling features to help operators move equipment safely and efficiently every day.
