14EH Equipment Trailer
Description
Part of the all-new X-Series, the 14EH Equipment Trailer from Big Tex Trailers is engineered for professionals who demand durability and innovation. The 14EH features APEX Fortified Lumber for superior deck durability and a Mega-Sized Toolbox for added storage capacity. It’s enhanced with a Full-Length Rub Rail, D-Rings, and Stake Pockets, providing multiple secure tie-down options for a variety of cargo. The 14EH revolutionizes loading and unloading with its optional Self-Stabilizing Mega Ramps, offering unparalleled flexibility for all your hauling needs.



Standard Features


2 – 7,000# Premium Cambered Axles with Quick-Lubricating Hubs

Forward Self-Adjusting Electric Brakes on All Hubs

Multi-Leaf Slipper Spring Suspension with Equalizer

Adjustable 2-5/16” Demco EZ Latch Coupler

12,000# Drop-Leg Jack (Side Wind)

8″ I-Beam Frame

3″ Channel Cross-Members on 16″ Centers

3/16″ Fabricated Front Stop Rail

APEX Fortified Lumber Floor

5′ Tall Stand-Up Ramps (Spring Assisted)

40” Cleated Dovetail

Stake Pockets Along Both Sides

7-Way RV Trailer Plug

LED DOT Stop, Tail, Turn & Clearance Lights

Sealed Modular Cold-Weather Wiring Harness

ST235/80 R-16 Load Range E Radial Tires

Rub Rail Along Both Sides

(6) 5/8″ D-Rings

Complete Breakaway System

Mega-Sized Integrated Tongue Box with Lockable Lid

Convenient Side-Step Access




Available Options


Adjustable Pintle Coupler

Adjustable Gooseneck Coupler

36″ Wide Mega Ramps (D3 Models Only)

Super-Wide Ramps with Blackwood Pro-Filled Dovetail

Tire Upgrade (Load Range G)

Spare Tire & Wheel

Additional Paint Colors

Lockable Toolbox on Gooseneck Models




Available Models & Specifications



Model
Pull Type
GVWR
GAWR
Empty Weight
Cargo Capacity
Bed Length
Bed Width




14EH-16D3A
Bumperpull
15,400 lbs
7,000 lbs
2,860 lbs
12,540 lbs
16′
83″


14EH-18D3A
Bumperpull
15,400 lbs
7,000 lbs
3,020 lbs
12,380 lbs
18′
83″


14EH-20D3A
Bumperpull
15,400 lbs
7,000 lbs
3,150 lbs
12,250 lbs
20′
83″


14EH-22D3A
Bumperpull
15,400 lbs
7,000 lbs
3,330 lbs
12,070 lbs
22′
83″


14EHG-20D3A
Gooseneck
15,900 lbs
7,000 lbs
3,740 lbs
12,160 lbs
20′
83″


14EHG-22D3A
Gooseneck
15,900 lbs
7,000 lbs
3,940 lbs
11,960 lbs
22′
83″


14EHG-24D3A
Gooseneck
15,900 lbs
7,000 lbs
4,140 lbs
11,760 lbs
24′
83″
