14PI Heavy Duty Tandem Axle Pipe Top Utility Trailer
Description
Facing down heavy-duty, demanding, and challenging loads? Then it’s time to call in the big guns with the 14PI Heavy Duty Tandem Axle Pipe Top Utility Trailer from Big Tex Trailers. This heavy-duty pipe-top equipment trailer is specifically designed and built to take on the toughest and heaviest loads. Coming standard with an adjustable forged coupler and LED lights, it’s a rugged and durable utility trailer that has the muscle for heavy-duty hauling and transport. It also features a treated pine floor for a professional-grade appearance and long-lasting durability.



Standard Features


2 – 7,000# Premium Cambered Axles with Quick-Lubricating Hubs

Forward Self-Adjusting Electric Brakes on All Hubs

Multi-Leaf Spring Suspension with Equalizer

Adjustable 2-5/16” Demco EZ Latch Coupler

8,000# Drop-Leg Jack (Side Wind)

5″ x 3″ x 5/16″ Angle Frame

3″ Channel Cross-Members on 16″ Centers

Treated Pine Floor

4′ Slide-In Channel Ramps

Outside Frame Stake Pockets

7-Way RV Trailer Plug

LED DOT Stop, Tail, Turn & Clearance Lights

Lifetime LED Lighting

ST235/80 R-16 Load Range E Tires

5/8″ D-Ring Tie-Downs

15″ Tall Open Sides

3″ x 3″ Square Tubing Top Rail

Professional Finish with Primer




Available Options


Adjustable Pintle Coupler

Blackwood Pro Rubber Infused Lumber Floor

1/8” Diamond Plate Steel Floor

5’ Stand-Up Ramps

Heavy Duty Integrated Ramp Gate

Additional Stake Pockets

Tire Upgrade (Load Range G)

Spare Tire & Wheel

Landscape Storage Box

Expanded Metal or Sheet Metal Side Enclosures

2′, 3′, or 4′ High Side Options

Car Hauler Style (No Side Rails)




Available Models & Specifications



Model
Pull Type
GVWR
GAWR
Empty Weight
Cargo Capacity
Bed Length
Bed Width




14PI-16
Bumperpull
14,000 lbs
7,000 lbs
2,740 lbs
11,260 lbs
16′
83″


14PI-18
Bumperpull
14,000 lbs
7,000 lbs
2,890 lbs
11,110 lbs
18′
83″


14PI-20
Bumperpull
14,000 lbs
7,000 lbs
3,040 lbs
10,960 lbs
20′
83″
