14GX Heavy Duty Tandem Axle Extra Wide Gooseneck Dump Trailer
Description
For the ultimate in strength and durability, the 14GX Heavy Duty Tandem Axle Extra Wide Gooseneck Dump Trailer is engineered to handle heavy-duty and extra-wide loads with maximum stability and efficiency. From its robust frame to a heavy-duty dump box with 10-Gauge steel floors, this trailer delivers superior performance for demanding jobs. Its full-featured box unit, optional accessories, and heavy-duty construction make it ideal for construction, landscaping, and industrial hauling.



Standard Features


2 – 7,000# Premium Cambered Axles with Quick-Lubricating Hubs

Forward Self-Adjusting Electric Brakes on Both Axles

Multi-Leaf Slipper Spring Suspension with Equalizer

8″ Seamless I-Beam Tongue Integrated with Frame

Round Adjustable Pin 2-5/16” Gooseneck Coupler

Dual 12,000# Drop-Leg Jacks (Side Wind)

8″ I-Beam Frame with 3″ Channel Cross-Members on 16″ Centers

10-Gauge Smooth Steel Floor

9″ x 72″ 14 Ga. Diamond Plate Double Broke Fenders

Stake Pockets Along Both Sides

7-Way RV Trailer Plug

Recessed, Grommet-Mounted LED Lighting

ST235/80 R-16 Load Range E Radial Tires

Side Spare Tire Mount

4 – 1/2″ D-Ring Tie-Downs Inside Bed

Rear Combo Gate (Barn Doors & Spreader Gate)

3″ x 2″ Rectangular Tubing Top Rail

Rear Stabilizer Stands

Lockable Pump and Battery Box

Fully-Formed Tarp Shroud with Tarp & Rear Tarp Rod Holders

5 Watt Solar Charger with Wireless Remote Ram




Available Options


Drop Axles (Lowers Deck Height to 24″)

Adjustable Pintle Coupler

Spare Tire & Wheel (ST235/80 R-16 LR-G)

Removable Deck on the Neck (Bolt-On 8′ W x 6′ L)

6.5′ Slide-In Ramp Package

24″ Expanded Metal Side Extensions

3′ or 4′ Solid Sheet Metal Sides

Optional Deck & Accessories

Additional J-Hooks for Cargo Control




Models & Specifications



Model
Pull Type
GVWR
GAWR (Ea. Axle)
Empty Weight
Cargo Capacity
Bed Length
Bed Width




14GX-16
Gooseneck
15,900 lbs
7,000 lbs
5,000 lbs
10,900 lbs
16′
83″


14GX-14
Gooseneck
15,900 lbs
7,000 lbs
4,640 lbs
11,260 lbs
14′
83″
