14ET Heavy Duty Tandem Axle Equipment Trailer

Description:
Engineered to handle the toughest hauling and equipment transportation tasks, the 14ET Heavy Duty Tandem Axle Equipment Trailer delivers unmatched versatility, durability, and strength. Ideal for construction professionals, landscapers, farmers, and anyone requiring heavy-duty hauling, this trailer combines a rugged frame, reinforced deck options, and premium suspension to tackle long, demanding hauls with ease. With multiple tie-down points, recessed LED lighting, heavy-duty ramps, and optional storage solutions, the 14ET is designed to maximize both efficiency and convenience.

Standard Features:


Axles: 2 – 7,000# Premium, Cambered Axles with Quick-Lubricating Hubs

Brakes: Forward Self-Adjusting Electric Brakes on Both Axles

Suspension: Multi-Leaf Slipper Spring with Equalizer

Coupler: 2-5/16″ Ball, Adjustable Demco EZ Latch Coupler (Bumper Pull); 2-5/16″ Round Gooseneck Coupler (Gooseneck models)

Safety Chains: 3/8″ Grade 70 with Safety Latch Hook (2 ea)

Jack: 12,000# Drop-Leg Jack (Side Wind); Dual Jacks on Gooseneck Models

Frame: 6″ Channel Cross-Members 3″ Channel on 16″ Centers

Front Stop Rail: 3/16″ Fabricated Front Stop Rail (Bumper Pull Only)

Floor Options: APEX Fortified Lumber, Blackwood Pro Rubber Infused Lumber, 1/8” Diamond Plate Steel Floor

Fenders: 9″ x 72″ 14 Ga. Diamond Plate Double Broke with Back

Ramps: 4’ Tall, 16″ Knee Ramps (Spring Assisted), 44″ Wide Mega Ramps (Dovetail only), 5′ Rear Slide-In Ramps (Straight Deck models), Super-Wide Ramps (60″ Tall x XX” Wide)

Dovetail: 3′ Cleated Dovetail, Blackwood Pro Dovetail (Standard with Super-Wide Ramps)

Stake Pockets: Along Both Sides (Quantity Varies by Length)

Trailer Plug: 7-Way RV Lights, Recessed, Grommet-Mounted LED Lighting

Wiring: Sealed, Modular Cold-Weather Wiring Harness

Tires: ST235/80 R-16 Load Range E Radial Tires; Tire Upgrade Available (ST235/80 R-16 LR-G)

Bolt Pattern: 8-Lug Wheels, Black Mod Steel

Spare Mount: Front Spare Tire Mount; Spare Tire & Wheel Optional

Paint Colors: Black, Red, Grey, White, Desert Tan, Jet Blue, Slime Green, Implement Green, Equipment Orange, Medium Yellow

Rubrail: Along Both Sides

Tie-Downs: (6) 5/8″ D-Rings; Extra 5/8″ D-Rings; Recessed D-Ring in Floor (Steel Floor Only)

Break-Away Kit: Complete Breakaway System with Zip Breakaway Cable

Storage: Tongue Tool Tray (Bumper Pull Only), Lockable Toolbox Between Risers (Gooseneck Model)

Models & Specifications:



Model
Pull Type
GVWR
GAWR (Ea. Axle)
Empty Weight
Cargo Capacity
Bed Length
Bed Width




14ET-20KR
Bumperpull
14,000 lbs
7,000 lbs
2,940 lbs
11,060 lbs
20′
83″


14ET-18KR
Bumperpull
14,000 lbs
7,000 lbs
2,740 lbs
11,260 lbs
18′
83″
